Nail Rolling Machine

High speed nail rolling machine STI-GSJ-1800

The nail rolling machine is an efficient solution designed for producing threaded nails, coil nail threads, and customized surface patterns on steel wire nails. The machine adopts advanced cold rolling forming technology, which creates strong and uniform thread profiles through pressure forming instead of material cutting. Machine is developed for nail manufacturers requiring high production capacity, stable operation, and flexible adjustment. With a maximum speed of 1800 nails per minute, this equipment significantly improves manufacturing efficiency while reducing labor requirements and production space.

It works as a high speed nail rolling machine with adjustable production speed from 0–1800 units/min. The main motor is equipped with a reliable frequency conversion system, allowing operators to easily adjust the running speed according to different nail sizes and production requirements.The machine can process nails with diameters from 1.8 to 3.6 mm and lengths from 25 to 100 mm. It is suitable for producing coil nail threads, full-thread nails, and other special nail designs used in construction and industrial fastening applications.

As an advanced iron nail rolling machine, it provides consistent rolling performance for various steel nail materials. The cold rolling process improves the surface strength of nails and enhances their holding force after installation.The machine is equipped with precision rolling dies to ensure stable thread forming quality. Different rolling dies can be customized according to customer nail specifications, allowing manufacturers to produce multiple nail types with one machine platform.

The machine is also widely applied as a wire nail rolling machine for processing common wire nails into threaded or patterned nails.This equipment integrates an automatic feeding system, vibration bowl, nail positioning mechanism, and collection system. When abnormal conditions such as nail jamming or incorrect feeding occur, the machine automatically stops operation and displays the fault information on the touch screen, reducing downtime and protecting the equipment.

The planetary nail rolling machine design provides balanced rolling pressure and stable nail forming performance. Multiple rolling components work together to achieve accurate thread depth and uniform surface patterns.

The machine is equipped with a large-diameter vibration feeding system (ø740 mm), providing fast feeding speed and stable operation. The vibration controller adopts a precision adjustment module, ensuring smooth speed control during long-term production.

Adjustable working speed through inverter control, Automatic stop protection for jammed nails,Touch screen operation interface, Customized rolling dies available, Stable vibration feeding system, Compact structure with reduced installation space

The nail rolling machine is suitable for manufacturing:

Coil nails, Threaded wire nails, Construction nails, Industrial fastening nails, Customized rolled nails
With high-speed performance, intelligent control functions, and reliable mechanical design, we provides professional nail rolling machine solutions for global nail production factories seeking higher efficiency and consistent product quality.
