Dry Drawing Machine
Dry Drawing Machine
Machine Model:Multi-Pass Dry Drawing Machine
Drawing Principle: Non-Slip
Maximum Reduction Ratio: 90%
Normal Production Speed: About 20 m/s
Description
Dry Drawing Machine for High Productivity Steel Wire Manufacturing
Product overview
Multi-pass dry drawing machine is designed for high-efficiency steel wire manufacturing where stable tension control and high reduction capacity are required. An advanced non-slip transmission system with independently driven capstans, ensuring precise control of wire tension throughout the drawing process.
Multi-pass non-slip dry drawing machine system is widely used in nail wire, mesh wire, galvanized wire, and low carbon steel wire production, offering excellent stability in continuous industrial operation.
Compared with traditional slip-type systems, this dry drawing machine delivers higher accuracy, better surface consistency, and improved production efficiency.
Structural design
The machine adopts a vertical and inclined capstan layout, including:
- Vertical block dry drawing machine structure
- Vertically oriented drums dry drawing machine configuration
- Capstan inverted vertical dry drawing machine transmission system
- Each capstan is independently driven by a high-performance AC motor, ensuring zero slip between drawing stages and stable wire deformation control.
Application range
This machine is suitable for medium to heavy-duty wire production, including:Low carbon steel wire
Galvanized wire, Nail wire, Mesh wire, Industrial construction wire, It is especially effective for high reduction ratio processes requiring flexible pass configuration.
Key advantages
Independent drive on each capstan, Non-slip drawing principle for stable tension, High reduction capability up to 90%, Excellent diameter accuracy, Reduced wire breakage rate, Flexible pass skipping system, Suitable for continuous heavy-duty production, Lower long-term maintenance cost, This makes it a highly efficient solution for modern wire plants requiring stable output and high productivity.
Frequently asked questions (FAQ)
1. What is a non-slip wire drawing machine?
Each capstan is independently driven to eliminate wire slippage and ensure precise tension control.
2. Can production passes be adjusted?
Yes, each drawing stage can be individually bypassed for flexible production setup, jump passes available.
3. What motors are used?
High-performance AC motors with vector inverter control, customized motor Brand available.
4. Is it suitable for continuous production?
Yes, it is designed for long-term heavy-duty industrial operation.
Customized production solutions
We provide complete engineering support for:
- Process design and capacity planning,
- Equipment configuration selection,
- Layout drawing optimization,
- Remote technical assistance,
- Installation and commissioning support, Turnkey wire production line solutions
